DSTREAM-ST Debug Probe

High-performance debug and trace capability, ideal for fast downloads and adaptive JTAG clock rates. DSTREAM-PT has the performance, adaptability-to-target, and broad Arm architecture support required for rapid development.

Debug protocol

Specification:

JTAG and Serial-Wire Debug

Trace capture

4-bit wide trace capture at up to 300 MHz DDR (600 Mbit/s per pin)

Bandwidth

1.2V - 3.3V (configurable by target)

Interface Vref

Total trace bandwidth up to 19.2 Gbps

Features

• Debug on Arm processors from Armv4 onwards as well as CoreSight trace

• USB 3.0 and Gigabit Ethernet for direct or remote host connections

• JTAG clock of up to 180 MHz for lightning fast software development

• Instrumentation trace and/or Cortex-M instruction trace streamed directly to host PC

• Wide range of target connectors

• Flexible DDR trace clock timing up to 300 MHz (600 Mbits/s per pin)

• Support for up to 4096 CoreSight devices (including CPUs)

• Remote target reset

• Device bring-up and test utilities

• Flexible architecture to support 3rd party IP and debuggers

Minimum software version

Arm Development Studio 2018.0 or DS-5 5.27
